Custom LED Solutions

In addition to the Platinum and Premium White Color Series, Promolux also manufactures LEDs customizable to exact energy management and merchandising specifications. Please consult us for your special requirements, as well as on-going product and specifications updates.

Custom LED options:

Tubes (T8 or T5):

  • All standard lengths (1-8ft) including non-standard linear sizes from 12” to 96”
  • Unique high definition colors with saturated CCT from 2500K to 6500K
  • External Driver (T8 & T5), Internal Driver (T8 Only)
  • Single End Power Input, Double End Power Input (Non-Polar)
  • Customizable IP (Ingress Protection)
  • Rotating & Lockable End Caps, Fixed, Hardwired (Pigtail) – G13 Bi-Pin for T8s, G5 for T5
  • High Power (Canopy/Cornice) – Customizable watts per foot
    Energy Saver (Shelf) – Customizable watts per foot
  • Frosted, Striped, Clear, V-Shaped Lens Options
  • 5 year warranty
  • DLC, UL, CE, VDE, cUL and LM79 & LM80 reports available

Spot Lights:

  • PAR38, PAR30, PAR20, MR16, GU10
  • 30,45,60 degree beam angles
  • Unique high definition colors with saturated CCT from 2500K to 6500K
  • Frosted or Clear lens options
  • Power Factor Conversion >0.95 or to spec
  • North American, European or Universal Voltages

Rigid Strips/Sticks:

  • All standard lengths (1-8ft) including non-standard linear sizes from 12” to 96”
  • Unique high definition colors with saturated CCT from 2500K to 6500K
  • Frosted, Striped, Clear or V-Shaped lens options
  • External 24V Constant Voltage Driver in various wattages
  • Customizable IP (Ingress Protection)
  • 30,45 or 60 degrees beam angle

In Development:

  • Track Lights, Down-Lights, Ceiling Panels, High and Low Bay, High Power Spots

As a custom manufacturer, we pride ourselves on flexibility and leading edge technology. If you’re interested in something that is not listed above, please contact us directly.
