Slimline Edge LED

SLIMLINE SERIES

The Promolux Slimline Edge LED is a linear LED bar designed for retail display lighting in supermarkets, specialty food and beverage shops, convenience stores, and other merchandising environments. Easy to install on metal shelves, the Slimline Edge features strong integrated magnets and multiple mounting angle options for flexible installation. With a 120° beam spread and proprietary chip colors, it delivers bright, even illumination for merchandise displays where product presentation and color appearance are important.

The Slimline Edge LED provides focused, balanced illumination for shelves and open display cabinets in both horizontal and vertical applications. Its Edge lens creates a 120° beam angle that helps distribute light evenly across displayed merchandise while reducing glare and reflective flash.

Available in multiple lengths, wattages, and color options, the Slimline Edge can be connected in a series up to 150W using direct end-pin connectors or extension cable cords. The aluminum profile includes strong magnetic mounting plates and supports fixed-angle mounting clips at 0°, 30°, 45°, and 60° for versatile installation.

Operating on a 24V system, the Slimline Edge is ideal for retail merchandising, food service displays, and specialty display applications where color consistency and presentation are critical.

Key Benefits
  • Connectable in a series up to 150W
  • Easy installation with integrated magnetic mounting
  • Optional mounting angles of 0°, 30°, 45°, and 60°
  • Wide 120° beam spread for shelf and display illumination
  • Bright, even linear lighting with balanced light distribution
  • Reduced glare and minimal reflective flash
  • Available in multiple lengths and wattages
  • Proprietary chip colors for color-critical display applications
  • IP65 rated
  • High CRI (>80) with high R9 and R12 values
  • 24V input with power factor greater than 0.9
  • Rated life of 50,000 hours
  • Available in Platinum, Premium White, 4000K, and other color options
Applications

The Slimline Edge LED is suitable for:

  • Supermarket shelving
  • Specialty food displays
  • Beverage displays
  • Convenience store merchandising
  • Open display cabinets
  • Horizontal display cases
  • Vertical display cases
  • Retail merchandising displays
  • Food service displays
  • Specialty retail displays where color presentation is important

Works with 24V Constant Voltage LED Driver (sold separately)

  • Connectable in a Series up to 150W
  • IP65
  • 120° Beam Angle
  • CRI: > 88+
  • High R9 & R12 Values
  • Power Factor: > 0.9
  • Voltage Input: 24V
  • Chips: 2835
  • Colors: Platinum (PL), Premium White+ (PW+), 3500K (35), 4000K (40)
Ways to Connect
  1. SB-CONNECT Connector / Jumper Cable (optional purchase)
  2. LED to LED
Installation

2 Different Ways

  1. Using pre-installed magnets
  2. Using Mounting Clips (multiple angles) & Screws (included)

See Spec Sheet for more information or visit our Youtube installation channel

Aged beef is exposed to light for weeks – sometimes months – in cold rooms like this one at Makro. That’s why lighting matters. Even under ideal refrigeration, improper lighting can trigger photo and lipid oxidation, causing discoloration, moisture loss, and off-odors long before the meat reaches the customer. With Promolux LEDs, you can maintain optimal appearance, minimize shrink, and support the full aging process, without compromising quality. Because when beef is on display this long, every wavelength counts.
